SKU
GX-603AWP
  • $2,125.20
  • $3,500.00 You Save 39.28%

Description

The A&D Apollo GX-603AWP IP65 washdown precision balance with internal calibration has a 620 gram capacity with a 0.001 gram readability and has a 5 x 5 inch (128 x 128mm) pan.

  • Increased productivity via faster stabilization times (1 second in fast mode).
  • Lower cost of ownership due to reduced number of parts and maintenance accessibility.
  • IP65 dust and water ingress protection
  • Basic weighing, Gross/Net/Tare display, parts counting (labeled not legal for trade) and percent weighing applications (MC only).
  • Plug in, turn on, screen blinks for 5 seconds to prompt user to level.
  • Bright-bubble – Large, easy-to-see, front mounted spirit level with LED Illumination.
  • Fly-thumbwheel is effortless and accessible allowing ergonomic adjustment with anti-slip feet.
  • Six straightforward keys – ON|OFF/ZERO, CAL, MODE, SAMPLE, PRINT, TARE.
  • Large Reverse Backlit LCD with black and white contrast provides excellent visibility.
  • Stainless Steel Pan and Dust-plate can be easily removed for cleaning.
  • Die-cast Aluminum housing provides extra stability and durability.
  • Standard RS-232C and USB – Toggle between the Quick USB mode or Virtual COM mode (bi-directional). A USB cable comes standard.
  • Security Slot – Anti-theft lock (such as Kensington) to prevent loss.
  • Internal Calibration – Easy one touch button performs and documents internal calibration.
  • Universal Flexi Coms (UFC): Edit serial data output making label printing possible.
  • Password-Protect: Offers password-protection uo 11 users and 1 administrator
  • GLP/GMP/GCP Compliance: Outputs manufacturer, model, serial number, ID, date, time, signature for full calibration report.
  • 5 year warranty
Technical Specifications:
Capacity 620g
Readability 0.001g
Pan size 5 x 5 inches / 128 x 128 mm
Repeatability (std dev) 0.001g
Linearity ±0.002 g
Accuracy immed.following cal ± 0.010 g
Stabilization time Approx. 1 sec (approx 0.8 sec for 5 g)
Sensitivity drift ±2 ppm / °C (10 °C to 30 °C / 50 °F to 86 °F, when automatic self-calibration is OFF)
Calibration wt 50g, 100g, (100g interval), 600g (Internal)
Display Reverse Backlit LCD (Character height: 17.8 mm)
Display refresh rate 5 times / second, 10 times / second or 20 times / second
Units g (gram), oz (ounces), lb (pound), lb-oz (pound-ounce), ozt (troy ounce), ct (metric carat), mom (momme), dwt (pennyweight), gr (grain), pcs (counting mode), % (percent mode), SG (specific gravity), and a user-programmable unit.
Counting mode, min unit mass 0.001g
Counting mode, # of samples 5, 10, 25, 50 or 100 pieces
Percent mode, min 100% ref mass 0.001g
Percent mode, min 100% display 0.01%, 0.1% or 1% (depends on the reference mass stored)
Operating environ ment 5 °C to 40 °C / 41 °F to 104 °F, 85% R.H. or less (no condensation)
Power supply / consumption AC adapter / approx. 30 VA
Communication interface Standard: RS-232C and USB
Optional: Quick USB, LAN Ethernet (FXi-08), USB Host (GXA-24), Bluetooth Converters: AD-8529PC-W, AD8529PR-W
Weighing Applications Counting with ACAI, % weighing, animal weighing, density determination, Statistical Caculation, Comparator HI|OK|LO, underhook, Gross/Net/Tare
Overall Dimensions (WxDxH) 212 (W) x 317 (D) x 93 (H) mm / 8.3 (W) x 12.5 (D) x 3.7 (H) in
Net weight Approx. 5 kg / 11 lb
Shipping Weight 14.3 lbs / 13 x 17 x 11 inches
