DISCONTINUED BY MANUFACTURER, PLEASE CALL FOR ALTERNATIVES
GF-K utilizes A&D's revolutionary Super Hybrid Sensor® (SHS) technology. SHS improves response speed, accuracy and minimizes maintenance costs. SHS combines the best of magnetic force restoration and single point parallelogram load cell technologies. Its unique design provides the fastest response speed in its class - just 1.5 seconds!
| Capacity | 10.1kg |
|---|---|
| Readability | 0.01g |
| Pan Size | 8.3 x 10.6" / 211 x 269mm |
| Units of measure | g, kg, oz, lb, lb-oz, ozt, dwt, ct, mm, GN, pcs, %, custom |
| Linearity | ±0.02 g |
| Repeatability (standard deviation) | 0.01 g |
| Sensitivity drift (10°C to 30°C / 50°F-80°F) | ±2 ppm/°C |
| Counting mode min. unit mass | 0.01g |
| Percentage mode min. 100% reference mass | 1 g |
| External calibration mass | 2, 3, 4, 5, 6, 7, 8 kg |
| Stabilization time | Approx. 1.5 seconds (typical in FAST mode) |
| Operating temperature | 5°C to 40°C / 41°F to 104°F, RH less than 85% (No condensation) |
| Display refresh | 5 times per second (stable) / 10 times per second |
| Counting mode sample size | 10, 25, 50 or 100 pieces |
| Percent mode min. 100% display | 0.01%, 0.1% , 1% (depending on reference mass) |
| External dimensions (W x D x H) | 300 x 355 x 111mm / 11.81 x 13.98 x 4.37" |
| Net weight | 8.3 kg / 18.3 lbs |
| Notes |
