METER ONLY, DOES NOT INCLUDE ELECTRODES
Ideal for checking solution conductivity and follow-up pH testing. The large color display is easy to read and easy on the eyes. Prompts make accuracy and repeatability easy for even the most complicated testing. If you need to add more channels for more or obtain more parameters from the same, simply remove the protective individual channel cover and add the new module.
- Customize the display to show only the information you need
- Change out modules to create the meter you need at any time
- Up to 6 point pH calibration with automatic recognition for USAIST and DIN buffers and electrode identification
- Fix errors without a complete recalibration with the calibration editing function
- Conductivity, TDS, salinity or resistivity capabilities
- Selectable reading reference temperatures of 5, 10, 15, 20 or 25 °C
- Linear, non-linear, nLFu or USP/EP curve options to get the most accurate conductivity result for your sample and temperature
- Choice of practical salinity or natural sea water curves for salinity readings
- Linear or ISO/EN 27888 curves for TDS
- Anyone can use this meter with its plain language screen prompts, function keys that update for easy selection and a multilanguage interface that supports English, Spanish, French, Italian, German and Chinese
- Don't miss a reading - AUTO-READ™ locks in the stable reading on your screen, ready indicator alerts when readings are stable and timed reading gathers data in specific time intervals or just once with single-shot mode
- Non-volatile memory holds up to 2000 data points with time and date stamp
- Stores up to 10 methods per channel allow for customized procedures to differentiate between tests and/or users
- Two USB and a RS232 port makes for easy data transfer and updating meter software
- Includes data analysis software for easy transferring of stored results or real-time viewing
- Control sample mixing directly from the meter without a separate stir plate when using with the Orion Star stirrer probe (cat. no. 096019, sold separately)
- Increase your productivity - with two Orion stirrer probe ports, add stirrers and modules to analyze two separate samples at the same time
- Included electrode arm and newly-designed probe holder make it easier to maintain and place probes into samples
- Works with almost every AC power source through the included universal power adapter
- IP54-rated housing handles splashes and cleans up easily
- 3 year meter replacement warranty
Technical Specifications: pH-range | -2.000 to 20.000 |
pH-resolution | Selectable 0.1, 0.01, 0.001 |
pH-relative accuracy | ±0.002 |
Calibration Points | Up to 6 |
Calibration Editing | Yes |
Adjustable ISO Point | Yes |
mV/Rel mV/ORP Range | ±2000.0 mV |
mV/Rel mV/ORP Resolution | 0.1 |
mV Relative Accuracy | ±0.2 mV or ±0.05% or reading, whichever is greater |
EH ORP Mode | Yes |
Inputs ph/ISE Module | BNC, reference pin |
Temperature input pH/ISE module | 8-pin min-DIN |
Conductivity Range | 0.001 µS to 3000 mS |
Conductivity Resolution | 0.001 µS minimum; 4 significant fugures minimum |
Conductivity Relative Accuracy | 0.5% reading ±1 digit |
Conductivity Reference Temp. | 5, 10, 15, 20, 25 ° C |
Conductivity Temp. Compensation | Linear (0 to 10.0%/°C), nLn, nLFu, USP/EP |
Conductivity Compatible Cell Constants | 0.001 to 199.9 |
Conductivity Calibration Points | Up to 6 points |
Conductivity Calibration Editing | Yes |
Resistivity Range | 2 ohm to 100 meg-ohm |
Resistivity Resolution | 2 ohms-cm |
Resistivity Relative Accuracy | 0.5% reading ±1 digit |
Salinity Type | Practical salinity or natural sea water |
Salinity Range | 0.01 to 80.0 ppt NaCl equivalent; 0.01 to 42 ppt sea water |
Salinity Resolution | 0.01 |
Salinity Relative Accuracy | ±0.1 |
TDS Range | 0 to 200 ppt |
TDS Resolution | 4 significant digits |
TDS Relative Accuracy | ±0.5% reading ±1 digit |
TDS Factor Range | Linear 0.01 to 10.00 |
Temperature Range | -5 to 105 °C, 23 to 221 °F |
Temperature Resolution | 0.1 |
Temperature Relative Accuracy | ±0.1 |
Temperature Offset Calibration | 1 point |
Input Conductivity Module | 8-pin min-DIN |
Electrode Supplied | None |
