SKU
EXF32086D
  • $19,841.90

Description

DISCONTINUED BY MANUFACTURER, PLEASE CALL FOR ALTERNATIVES

The Revco EXF32086D upright ultra-low temperature freezer has a capacity of 17.3 cubic feet with a temperature range of -50 to -86°C and requires 208/230V power. Ensure uncompromised sample protection for -50° to -86°C applications with Thermo Scientific™ Revco™ ExF -86°C Upright Ultra-Low Temperature Freezers, designed for daily sample protection and dependability.

Features:

  • State-of-the-art refrigeration system with rugged construction
  • Eye-level, easy-to-use microprocessor control panel
  • Five interior compartment doors to reduce cold air loss and improve temperature recovery after door closings
  • Vacuum relief port permits easy access after door openings

Construction:

  • Stainless steel interior in four sizes: 13, 17, 23 and 28 cu.ft. (240, 320, 400 and 600L) to accommodate specific lab space and capacity requirements
  • Heavy gauge, cold-rolled steel exterior construction with a powder coat paint finish that resists chipping and rust
  • 5" (127mm) foamed-in-place, polyurethane insulation
  • Sturdy, solid, stainless steel shelving to support a full product load

Optional Accessories:

  • Optional CO2 or LN2 safety back-up system for additional protection in the event of a power or mechanical failure
  • Optional, built-in chart recorder for continuous monitoring

Includes:

  • Ergonomic, lockable door handle
  • Power Management System with low voltage surge protection and buck/boost
  • Easy-to-remove air filter
  • Two (25mm) access ports
Technical Specifications:
Capacity, Volume17.3 CU FT / 288L
Capacity, Shelf150 Lb
2ml Vial Capacity per Freezer32,000
Access SecuritySingle ID
Chart RecorderOptional 7-day chart recorder
Temperature Range-50° to -86°C
TypeUltra-Low Freezer, Upright
Certifications/CompliancecULus, ENERGY STAR
Electrical Requirements208-230V, 60Hz, 12A
Electrical Plug TypeNEMA 6-15
Data Outputsdry contacts - standard, PT100 probe Optional
ControlLED Digital Controller
Exterior Dimensions (L x W x H)38.9 x 33.3 x 77.9 in. (98.8 x 84.6 x 197.9cm)
Interior Dimensions (D x W x H)25.3 x 23 x 51.5 in. (64.3 x 58.4 x 130.8cm)
InteriorPainted Galvaneel, Stainless-Steel Optional
Inner Doors5
Voltage CompensationBuck/Boost
Holds320 boxes
Backup SystemOptional CO2 or LN2
Smart View CompatibleYes
Shipping Weight763
